ŠPECIFIKÁCIA
RÁM: All New Series 4 Alloy Frame, 150mm Multitrac suspension, Integrated Battery/On-switch/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor
VIDLICA: Rock Shock 35 Gold RL 29″, Motion Control Damper, 160mm Travel, Maxle Stealth Axle, 44mm Offset
TLMIČ: Rock Shock Super Deluxe Coil R, Rebound Adjustment, 205x65mm, 25mmxM8 Lower Hardware, S/M Spring Rate = 300lb, L/XL Spring Rate = 400lb
RÁFKY: Front: Marin Aluminum Double Wall, 29″ Diameter, 32mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible; Rear: Marin Aluminum Double Wall, 27.5″ Diameter, 38mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible
ZADNÝ NÁBOJ: Forged Alloy, E-Bike Specific Design, 148x12mm, Quad Sealed Bearings, Disc, 32H, Standard Freehub Body
PREDNÝ NÁBOJ: Shimano MT-410B, 110x15mm, centerlock Disc, 32H
ŠPICE: 14g Black Stainless Steel
PLÁŠTE / DUŠE: Front: Maxxis Assegai 29×2.5″, 3C MaxxTerra, Double Down, Tubeless Compatible Rear: Maxxis Minion DHR II 27.5×2.8, 3C Maxx Terra, EXO+, Tubeless Compatible
ZADNÝ MENIČ: Shimano Deore, Direct Attachment, 10-Speed
RADIACE PÁČKY: Shimano Deore, I Spec EV, 10-Speed
KĽUKY S PREVODNÍKMI: Marin Forged Alloy 165mm Length, Narrow Wide 38T Chainring
MOTOR: Shimano STEPS E7000
REŤAZ: KMC X-10E, Silver
KAZETA: Shimano Deore 10-speed 11-46T
BRZDY PREDNÉ: Shimano MT420, 4-Piston Hydraulic Disc Brake, 203mm Rotor
BRZDY ZADNÉ: Shimano MT420, 4-Piston Hydraulic Disc Brake, 203mm Rotor w/ Speed Sensor
BRZDOVÉ PÁKY: Shimano MT4100 Hydraulic Lever, I-Spec EV Compatible
RIADÍTKA: Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
PREDSTAVEC: Marin 3D Forged Alloy, 35mm
MADLÁ: Marin Single Clamp Locking
HLAVOVÉ ZLOŽENIE: FSA No 57, Sealed Cartridge Bearings, 1 1/8″ x 1 1/2”
SEDLOVKA: TranzX YSP23J, 30.9mm, Travel S=125mm, M/L=150mm, XL=175mm
SEDLO: Marin E-MTB Saddle
PEDÁLE: Marin MTB Plastic
BATÉRIA: BT-8035, Internal 504Wh
DISPLEJ: SC-E7000 Display
OVLÁDANIE: SW-E7000 Left Hand Switch for Assist Mode Change
DOPLNKY: e13 Plus Chainguide, Aluminum Plate
NABÍJAČKA: Shimano Battery Charger EC-E6002
